Generic Chicken Wire Mesh, 20 Gauge, 2 Kg, 3 Feet Height

Product Highlights

• Function: Plaster reinforcement, crack prevention, fencing, and insulation cladding
• Pack Weight / Length: 2 kg (14 metres)
• Standard Height: 3 Feet (approx. 36 inches)
• Gauge / Thickness: 20 Gauge (0.8 mm – 0.9 mm)
• Material: Galvanized steel — rust and corrosion resistant
• Mesh Pattern: Hexagonal Wire Netting

Product Description

Generic Chicken Wire Mesh (Hexagonal Wire Netting) is a versatile, professional-grade galvanized steel mesh widely used by masons, contractors, and builders across Bangalore for plaster reinforcement, wall crack prevention, concrete screeding, and boundary fencing. Its hexagonal pattern distributes stress evenly across the plastered surface, significantly reducing the risk of shrinkage cracks in new construction and renovation projects.

At 20 gauge (0.8 mm – 0.9 mm thickness), the mesh provides the ideal balance of strength and flexibility — strong enough to reinforce plaster and mortar layers, yet easy to cut, shape, and fix to masonry, brick, AAC block, and concrete surfaces. The galvanized coating ensures long-term corrosion and rust resistance even in Bangalore's humid monsoon conditions.

Each roll contains 14 metres of mesh at 3-foot (36-inch) height — well suited for small-to-mid residential repairs, pillar reinforcement, column-to-wall junctions, and agricultural fencing projects.

Recommended Applications

• Plaster Reinforcement: Prevents shrinkage cracks in wall and ceiling plastering for new construction and renovation — the most common use on Bangalore construction sites
• AAC Block & Brick Junction Reinforcement: Bridges the interface between dissimilar materials (brick, AAC block, RCC column) where differential movement causes cracking
• Concrete Screeding: Adds tensile reinforcement to thin floor screed and topping layers to improve strength and prevent cracking
• Industrial Pipe & Boiler Insulation: Wraps around pipes, ducts, and boilers to hold insulation materials firmly in place
• Boundary & Poultry Fencing: Cost-effective perimeter fencing for residential plots, agricultural land, and poultry enclosures
• Garden & Landscape Protection: Protective barriers around plants, saplings, and garden beds against animals and pests

Installation Guidelines

FAQs

1) How much area does the 2 kg (14 metre) roll cover?

The 2 kg roll provides 14 metres of mesh at 3-foot (36-inch) height, giving a total coverage area of approximately 4.2 sq. metres (roughly 45 sq. ft.) when laid flat. For wall plastering, this is well suited for small-to-mid residential repairs, column-to-wall junctions, pillar reinforcement, and short fencing runs.

2) How do I fix chicken wire mesh to a wall for plastering?

For masonry and brick walls, use U-nails or steel staples spaced every 6–8 inches, pulling the mesh taut to prevent bulging during plastering. For AAC block surfaces, pre-drill and use appropriate fasteners. For metal frames, use 20-gauge binding wire at multiple tie points. The mesh must be flat and fully in contact with the substrate before applying plaster.

3) Will the mesh rust if exposed to moisture during construction?

The galvanized coating provides strong corrosion resistance for normal construction exposure. However, cut edges should be tucked inward wherever possible, and for highly humid environments, treat exposed cut ends with a zinc-rich cold galvanizing spray. Store the unused portion of the roll in a dry, covered area to preserve the factory finish.

4) Can chicken wire mesh be used for structural concrete slabs?

No. Chicken wire mesh is for lightweight reinforcement — plastering, screeding, and fencing. For load-bearing structural concrete slabs, beams, or columns, use heavy-duty welded wire fabric or TMT rebars, which are designed for high-tensile structural loads. Using chicken wire for structural applications is not recommended and unsafe.

5) Why is my plaster still cracking even after fixing the mesh?

Common causes include: (1) Mesh not pulled tight — any slack causes the mesh to shift during plastering; (2) Insufficient overlap at joins — minimum 2-inch overlap required; (3) Mesh placed too close to the surface — it must be embedded in the middle of the plaster layer, not near the face; (4) Plaster mix too dry or applied too thick in a single coat without allowing intermediate curing.

6) Can I join two cut sections from the same roll for a longer run?

Yes. Overlap the ends by at least 3 hexagonal cells and use pliers to twist the wire ends of one section around the adjacent wires of the other, creating a secure, seamless connection that will not pull apart under tension. For fencing, also use a vertical post at every join point for added stability.

7) How should I store the remaining mesh after cutting what I need?

Re-roll the unused mesh tightly and store it vertically in a dry, covered area. Avoid placing heavy materials on top, as kinks in the 20-gauge wire are difficult to flatten during installation. If the mesh gets muddy on site, rinse with clean water and allow to dry completely before reuse.
