Ebco Eurolift Bi-Fold Door System, Soft Close, Anthracite
Ebco Eurolift Bi-Fold Door System, Soft Close, Anthraciteಉಪಲಬ್ದವಿದೆ
ನಿಯಮಿತ ಬೆಲೆ
Rs. 2,848.00
ನಿಯಮಿತ ಬೆಲೆ
Rs. 4,024.00
ಮಾರಾಟ ಬೆಲೆ
Rs. 2,848.00
ಘಟಕ ಬೆಲೆ
₹0.0/
Incl GST
ಚೆಕ್ಔಟ್ನಲ್ಲಿ ಶಿಪ್ಪಿಂಗ್ ಅನ್ನು ಲೆಕ್ಕಹಾಕಲಾಗುತ್ತದೆ.
ಪಿಕಪ್ ಲಭ್ಯತೆಯನ್ನು ಲೋಡ್ ಮಾಡಲು ಸಾಧ್ಯವಾಗಲಿಲ್ಲ
Product Highlights
Quick Answer: What is Ebco Eurolift Bi-fold Door System used for?
Ebco Eurolift Bi-fold Door System is a dual-door vertical folding mechanism with soft-close functionality, designed for overhead kitchen cabinets where doors fold upward in sync, providing wide access to storage with built-in damping for silent operation.
- Manufacturer: Ebco
- Mechanism: Dual-door vertical bi-fold
- Finish: Anthracite
- Heights Available: 600mm (585-630mm), 720mm (690-750mm)
- Mounting: Left (L) or Right (R) side specific
- Cabinet Width: Up to 900mm (single side)
Product Description
Ebco Eurolift Bi-fold Door System revolutionizes overhead cabinet access with its innovative dual-door vertical folding mechanism. Both doors fold upward in perfect synchronization, creating wide, unobstructed access to your overhead storage while the built-in soft-close damping ensures silent, gentle closing every time.
Available in two height ranges (600mm for 585-630mm cabinets and 720mm for 690-750mm cabinets) with left or right side mounting options, this anthracite-finished system accommodates cabinets up to 900mm wide. The complete installation kit includes the bi-fold lift mechanism, cover plate, hinge clip-on bracket, and all necessary mounting hardware for professional installation.
Technical Specifications (Quick Reference)
| Specification | Details |
|---|---|
| Manufacturer | Ebco |
| Mechanism Type | Dual-door vertical bi-fold |
| Finish | Anthracite |
| 600mm Model Range | 585-630mm cabinet height |
| 720mm Model Range | 690-750mm cabinet height |
| Mounting Options | Left (L) or Right (R) side specific |
| Cabinet Width | Up to 900mm (single side); use double for >900mm |
| Door Compatibility | Aluminum profile or wooden doors |
| Package Contents | Bi-fold lift mechanism, cover plate, hinge clip-on bracket, mounting plates and screws |
Recommended Applications
- Overhead Kitchen Cabinets: Perfect for upper wall units requiring wide access
- Modern Wall Units: Contemporary kitchen designs with handleless aesthetics
- Premium Modular Kitchens: High-end installations requiring smooth operation
- Space-Constrained Areas: Where traditional swing doors would obstruct movement
- Handleless Cabinet Doors: Sleek, minimalist kitchen designs
- Residential Renovations: Upgrade existing overhead cabinets with modern mechanisms
Installation Guidelines
- Measure Cabinet Height: Select 600mm (585-630mm) or 720mm (690-750mm) model based on cabinet dimensions
- Determine Mounting Side: Choose Left (L) or Right (R) side mounting based on cabinet configuration
- Install Mounting Plates: Attach mounting plates to cabinet interior using provided screws
- Mount Bi-fold Mechanism: Secure the lift mechanism to installed mounting plates
- Attach Hinge Brackets: Install clip-on hinge brackets to cabinet doors
- Connect Doors: Attach doors to bi-fold mechanism and adjust for smooth operation
- Install Cover Plate: Add cover plate for finished appearance
- Test Soft-Close: Verify smooth upward folding and soft-close damping function
FAQs
1) What does bi-fold mean?
Bi-fold means both doors fold upward together in synchronized motion, creating wide access to the cabinet interior without doors swinging outward.
2) How do I choose between left and right mounting?
The mounting side refers to which side the mechanism is installed on. Stand facing the cabinet and determine if the mechanism should be on the left or right side.
3) What cabinet heights are compatible?
The 600mm model fits 585-630mm cabinets, while the 720mm model fits 690-750mm cabinets. Measure your cabinet height before ordering.
4) Can I use this on cabinets wider than 900mm?
For cabinets wider than 900mm, use double-sided installation with both left and right mechanisms for proper support and operation.
5) Does this work with any door type?
Yes, the system is compatible with both aluminum profile and wooden doors, providing flexibility for various kitchen designs.
6) What is the soft-close functionality?
The built-in damping mechanism ensures doors close silently and gently, preventing slamming and extending the life of your cabinets.
7) Is professional installation required?
While DIY installation is possible with the complete kit, professional installation is recommended to ensure proper alignment and smooth operation.
Why Buy from HomeRun?
- Authentic Ebco Hardware: Verified genuine products
- Complete Installation Kit: All mounting hardware included
- Bangalore Fulfilment: Quick local availability
Returns & Exchange Policy
- Return within 72 hours of delivery for:
- Damaged or defective product
- Wrong or missing item
- Product cannot be returned once installed or used
- Refer to Refund Policy for complete details
