Viking Floor Drain Jali, Round, 125mm

Product Highlights

• Manufacturer: Viking India — Professional Drainage Solutions Since 1966
• Model: Round Floor Drain Jali with Double Locking Frame
• Product Code: 40906-A
• Size: 125mm (5") overall diameter | 95mm effective drain area
• Material: SS430 Stainless Steel — 16–18% chromium ferritic grade
• Finish: Polished chrome mirror-bright surface
• Frame Design: Double locking frame — prevents shifting and displacement
• Waste Pipe Hole: 32mm diameter for standard drainage pipe connection
• Flow Capacity: 45 LPM
• Warranty: Viking India manufacturer warranty

Product Description

Viking Floor Drain Jali Round 125mm (Product Code: 40906-A) is a premium SS430 stainless steel floor drain from Viking India — a manufacturer with over 58 years of drainage product heritage since 1966. At 125mm (5 inches) overall diameter with a 95mm active drain area and a rated flow capacity of 45 LPM, it delivers efficient water removal for bathrooms, kitchens, balconies, terraces, and utility areas. The integrated 32mm waste pipe hole accommodates standard drainage pipe connections directly, eliminating the need for a separate fitting at the outlet — making it a complete, ready-to-install floor drain solution.

What distinguishes the 40906-A from standard drop-in drain jalis is its double locking frame design — a two-point securing system that locks the jali into the frame and the frame into the floor, preventing accidental displacement from foot traffic, cleaning, or water pressure. Built from SS430 ferritic stainless steel (16–18% chromium composition) with a polished chrome mirror finish, it offers superior corrosion resistance to bathroom chemicals, hard water minerals, and persistent moisture — maintaining its appearance and structural integrity over years of daily use without rusting, staining, or degrading. The low-profile 8mm frame height and 15mm installation depth minimise impact on floor level, making it suitable for both new construction and retrofit installations.

Technical Specifications

SS430 Stainless Steel — Material Specification

Recommended Applications

Why Buy from HomeRun?

FAQs

1) What does the double locking frame do — is it significantly better than a standard drop-in drain jali?

A standard drop-in drain jali simply rests in the drain frame by gravity and can be dislodged by foot pressure, mop contact, or strong water flow — creating a tripping hazard and an untidy appearance. The double locking frame on the Viking 40906-A uses a two-point mechanism that locks the jali into the frame and the frame into the floor recess, preventing accidental displacement under any normal bathroom or kitchen use condition. For commercial or high-traffic environments where the drain is regularly stepped on or mopped over, the locking system is a meaningful safety and maintenance advantage over standard alternatives.

2) What is the difference between SS430 and SS304 stainless steel for a floor drain — is SS430 good enough?

SS304 contains nickel in addition to chromium, giving it higher corrosion resistance in aggressive environments such as coastal salt-spray or industrial chemical exposure. SS430 (16–18% chromium, no nickel) is the appropriate and widely accepted grade for indoor floor drain applications — bathrooms, kitchens, balconies, and utility areas — where the primary threats are water, humidity, cleaning agents, and organic waste. SS430 handles these conditions reliably at lower cost than SS304. SS304 or SS316 would only be necessary for marine, outdoor coastal, or industrial drainage applications where the Viking 40906-A is not specified.

3) What size waste pipe does this drain connect to, and is it compatible with standard Indian plumbing?

The Viking 40906-A has an integrated 32mm diameter waste pipe hole — the standard size for bathroom and kitchen floor drain waste connections in Indian residential construction. This is compatible with standard UPVC and PVC waste pipes used across Indian plumbing systems. No additional reducer or adaptor is required for a standard installation. If your drainage system uses a different pipe size, consult your plumber before ordering.

4) Can this drain be installed on a terrace or balcony exposed to rain and sunlight?

Yes — SS430 stainless steel is suitable for outdoor balcony and terrace drainage where the drain is exposed to rainwater, sunlight, and temperature cycling. The 45 LPM flow rate is sufficient to handle heavy monsoon rainfall drainage on standard residential balcony and terrace areas. The polished chrome finish maintains its appearance in outdoor conditions without rusting or pitting under normal weathering. For coastal properties within direct salt-spray distance of the ocean, SS304 grade drains would offer better long-term corrosion resistance.

5) How is the Viking 40906-A installed — does it require a plumber or can a tiler fit it during floor work?

Floor drain installation is typically done by the tiler during floor laying — the drain frame is set into the screed at the correct depth (15mm total installation depth) before tiling, and the waste pipe is connected to the 32mm outlet below the slab. The jali and locking mechanism are fitted after tiling is complete. A plumber is needed for the underground waste pipe connection, but the above-floor drain installation itself is within a tiler's scope. Ensure the drain is positioned at the lowest point of the floor slope during installation to ensure complete water drainage toward the outlet.
